2G-50-Writer-Retest: everything (scoped)
client side baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
server side baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
all sides baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
highlighted cell(s) above show current scope
links point to other scopes

1. Load

Load Count
(xact/sec)		 Volume
(Mbits/sec)
offered 12.23 0.98
measured 12.23 0.97
Load trace
load.trace.scope=sides=server__phases=inc2

The load table shows offered and measured load from server side point of view. Offered load statistics are based on the request stream. Measured load statistics are based on reply messages. The 'count' column depicts the number of requests or responses.

The 'volume' column is a little bit more tricky to interpret. Offered volume is reply bandwidth that would have been required to support offered load. This volume is computed as request rate multiplied by measured mean response size. Measured volume is the actual or measured reply bandwidth.




2. Hit Ratios

Hit Ratios DHR
(%)		 BHR
(%)
offered 0.00 0.00
measured 0.00 0.00

The server-side hit ratios should always be zero. If a request reaches a server, it is, by definition, a miss.

A better way to measure hit ratio is to compare client- and server-side traffic. A hit ratio table based on such a comparison is available elsewhere.




3. Concurrent HTTP transaction level table

Transaction state Number of times Mean concurrency level
entered left
active 14692.00 14692.00 0.30
waiting 0.00 0.00 0.00
concurrent HTTP transaction level trace
xact.level.trace.scope=sides=server__phases=inc2

TBD.




4. Concurrent HTTP/TCP connection level table

Connection state Number of times Mean concurrency level
entered left
open 14717.00 14692.00 32.09
established 14715.00 14692.00 32.00
concurrent HTTP/TCP connection level trace
conn.level.trace.scope=sides=server__phases=inc2

TBD.




5. Population level table

Number of agents Mean population level
created destroyed
0.00 0.00 513.00
population level trace
populus.level.trace.scope=sides=server__phases=inc2

Populus is a set of all live robot or server agents. While alive, an agent may participate in HTTP transactions or remain idle.




6. Traffic stream table

Stream Contribution Rates Totals
Count
(%)		 Volume
(%)		 Count
(xact/sec)		 Volume
(Mbits/sec)		 Count
(xact,M)		 Volume
(Gbyte)
"foreign" 0.00 0.00 0.00 0.00 0.00 0.00
"image" 53.81 25.84 6.58 0.25 0.01 0.04
"HTML" 10.39 9.09 1.27 0.09 0.00 0.01
"download" 0.35 14.57 0.04 0.14 0.00 0.02
"applet" 0.26 0.12 0.03 0.00 0.00 0.00
"other" 14.63 35.97 1.79 0.35 0.00 0.05
all content types 79.43 85.58 9.71 0.83 0.01 0.12
hits 0.00 0.00 0.00 0.00 0.00 0.00
misses 79.43 85.58 9.71 0.83 0.01 0.12
hits and misses 79.43 85.58 9.71 0.83 0.01 0.12
ims/200 4.74 4.41 0.58 0.04 0.00 0.01
ims/304 3.40 0.04 0.42 0.00 0.00 0.00
all ims 8.14 4.45 0.99 0.04 0.00 0.01
cachable 45.42 52.78 5.55 0.51 0.01 0.08
not cachable 34.01 32.80 4.16 0.32 0.00 0.05
cachable and not 79.43 85.58 9.71 0.83 0.01 0.12
fill 45.42 52.78 5.55 0.51 0.01 0.08
reload 11.54 8.80 1.41 0.09 0.00 0.01
abort 0.08 0.03 0.01 0.00 0.00 0.00
redirected request 0.00 0.00 0.00 0.00 0.00 0.00
reply to redirect 0.00 0.00 0.00 0.00 0.00 0.00
HEAD 0.03 0.00 0.00 0.00 0.00 0.00
POST 0.87 1.17 0.11 0.01 0.00 0.00
PUT 0.00 0.00 0.00 0.00 0.00 0.00
all non-gets 0.89 1.17 0.11 0.01 0.00 0.00
all replies 100.00 100.00 12.22 0.97 0.01 0.14

The 'Stream' table provides count and volume statistics for many classes of transactions. The 'Contribution' columns show count- and volume-based portions of all transactions. The 'Rates' columns show throughput and bandwidth measurements. The 'Totals' columns contain the total number of transactions and the total volume (a sum of individual response sizes) for each stream.

Note that some streams are a combination of other streams. For example, the 'all ims' stream contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' stream) or '304 Not Modified' (the 'ims/304' stream) responses.

Many combination streams, such as 'all content types' or 'hits and misses' stream, contribute less than 100% because properties like content type or hit status are distinguished for 'basic' transactions only. A basic transactions is a simple HTTP GET request resulted in a '200 OK' response. Various special transactions such as IMS or aborts do not belong to the 'basic' category.

The 'Object' table contains corresponding response time and size statistics for streams.




7. Object kind table

Object Response time (msec) Size (KBytes)
Min Mean Max Min Mean Max
"foreign" n/a n/a n/a n/a n/a n/a
"image" n/a n/a n/a 0.27 4.90 35.88
"HTML" n/a n/a n/a 0.31 8.93 63.86
"download" n/a n/a n/a 18.30 427.92 1304.11
"applet" n/a n/a n/a 0.83 4.60 9.46
"other" n/a n/a n/a 7.67 25.10 72.60
all content types n/a n/a n/a 0.27 11.00 1304.11
hits n/a n/a n/a n/a n/a n/a
misses 0.00 2556.10 12113.00 0.27 11.00 1304.11
hits and misses 0.00 2556.10 12113.00 0.27 11.00 1304.11
ims/200 2.00 2563.67 5873.00 0.29 9.49 264.30
ims/304 1.00 2594.57 5544.00 0.06 0.11 0.13
all ims 1.00 2576.57 5873.00 0.06 5.57 264.30
cachable 0.00 2561.15 12113.00 0.33 11.86 1304.11
not cachable 1.00 2549.37 6278.00 0.27 9.84 113.04
cachable and not 0.00 2556.10 12113.00 0.27 11.00 1304.11
fill 0.00 2561.15 12113.00 0.33 11.86 1304.11
reload 0.00 2508.70 13479.00 0.00 7.79 1304.10
abort 507.00 2350.58 3938.00 0.00 3.77 32.52
redirected request n/a n/a n/a n/a n/a n/a
reply to redirect n/a n/a n/a n/a n/a n/a
HEAD 1801.00 2296.00 3044.00 0.29 0.34 0.35
POST 8.00 2599.07 5835.00 0.41 13.76 414.03
PUT n/a n/a n/a n/a n/a n/a
all non-gets 8.00 2589.82 5835.00 0.29 13.35 414.03
all replies 0.00 2552.60 13479.00 0.00 10.21 1304.11

The 'Object' table provides response time and response size statistics for many classes of transactions.

Note that some classes are a combination of other classes. For example, the 'all ims' class contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' class) or '304 Not Modified' (the 'ims/304' class) responses.

Some statistics may not be available because either no objects of the corresponding class were seen during the test or no facilities to collect the stats exist for the class. The former can be verified using a 'Stream' table.




8. Errors

No errors detected in the given scope.


9. Object '"foreign"'

No instances of this object class were observed or recorded in the given scope.


This object class represents one of the content types specified in the PGL workload file and labeled there as "foreign".


10. Object '"image"'

contribution: 53.81% by count and 25.84% by volume
rates: 6.58xact/sec or 0.25Mbits/sec
totals: 0.01Mxact and 0.04GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.27KBytes min, 4.90KBytes mean, and 35.88KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "image".


11. Object '"HTML"'

contribution: 10.39% by count and 9.09% by volume
rates: 1.27xact/sec or 0.09Mbits/sec
totals: 0.00Mxact and 0.01GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.31KBytes min, 8.93KBytes mean, and 63.86KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "HTML".


12. Object '"download"'

contribution: 0.35% by count and 14.57% by volume
rates: 0.04xact/sec or 0.14Mbits/sec
totals: 0.00Mxact and 0.02GByte
response time: n/a min, n/a mean, and n/a max
response size: 18.30KBytes min, 427.92KBytes mean, and 1304.11KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "download".


13. Object '"applet"'

contribution: 0.26% by count and 0.12% by volume
rates: 0.03xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.83KBytes min, 4.60KBytes mean, and 9.46KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "applet".


14. Object '"other"'

contribution: 14.63% by count and 35.97% by volume
rates: 1.79xact/sec or 0.35Mbits/sec
totals: 0.00Mxact and 0.05GByte
response time: n/a min, n/a mean, and n/a max
response size: 7.67KBytes min, 25.10KBytes mean, and 72.60KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "other".


15. Object 'all content types'

contribution: 79.43% by count and 85.58% by volume
rates: 9.71xact/sec or 0.83Mbits/sec
totals: 0.01Mxact and 0.12GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.27KBytes min, 11.00KBytes mean, and 1304.11KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all replies' class.




16. Object 'hits'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'hits and misses' class.




17. Object 'misses'

contribution: 79.43% by count and 85.58% by volume
rates: 9.71xact/sec or 0.83Mbits/sec
totals: 0.01Mxact and 0.12GByte
response time: 0.00msec min, 2556.10msec mean, and 12113.00msec max
response size: 0.27KBytes min, 11.00KBytes mean, and 1304.11KBytes max
response time distribution
object.misses.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.misses.size.fig.scope=sides=server__phases=inc2
response time trace
object.misses.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'hits and misses' class.




18. Object 'hits and misses'

contribution: 79.43% by count and 85.58% by volume
rates: 9.71xact/sec or 0.83Mbits/sec
totals: 0.01Mxact and 0.12GByte
response time: 0.00msec min, 2556.10msec mean, and 12113.00msec max
response size: 0.27KBytes min, 11.00KBytes mean, and 1304.11KBytes max
response time distribution
object.hits_and_misses.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.hits_and_misses.size.fig.scope=sides=server__phases=inc2
response time trace
object.hits_and_misses.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




19. Object 'ims/200'

contribution: 4.74% by count and 4.41% by volume
rates: 0.58xact/sec or 0.04Mbits/sec
totals: 0.00Mxact and 0.01GByte
response time: 2.00msec min, 2563.67msec mean, and 5873.00msec max
response size: 0.29KBytes min, 9.49KBytes mean, and 264.30KBytes max
response time distribution
object.ims_sc200.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.ims_sc200.size.fig.scope=sides=server__phases=inc2

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all ims' class.




20. Object 'ims/304'

contribution: 3.40% by count and 0.04% by volume
rates: 0.42xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 1.00msec min, 2594.57msec mean, and 5544.00msec max
response size: 0.06KBytes min, 0.11KBytes mean, and 0.13KBytes max
response time distribution
object.ims_sc304.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.ims_sc304.size.fig.scope=sides=server__phases=inc2

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all ims' class.




21. Object 'all ims'

contribution: 8.14% by count and 4.45% by volume
rates: 0.99xact/sec or 0.04Mbits/sec
totals: 0.00Mxact and 0.01GByte
response time: 1.00msec min, 2576.57msec mean, and 5873.00msec max
response size: 0.06KBytes min, 5.57KBytes mean, and 264.30KBytes max
response time distribution
object.ims_scAll.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.ims_scAll.size.fig.scope=sides=server__phases=inc2
response time trace
object.ims_scAll.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




22. Object 'cachable'

contribution: 45.42% by count and 52.78% by volume
rates: 5.55xact/sec or 0.51Mbits/sec
totals: 0.01Mxact and 0.08GByte
response time: 0.00msec min, 2561.15msec mean, and 12113.00msec max
response size: 0.33KBytes min, 11.86KBytes mean, and 1304.11KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.cachable.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'cachable and not' class.




23. Object 'not cachable'

contribution: 34.01% by count and 32.80% by volume
rates: 4.16xact/sec or 0.32Mbits/sec
totals: 0.00Mxact and 0.05GByte
response time: 1.00msec min, 2549.37msec mean, and 6278.00msec max
response size: 0.27KBytes min, 9.84KBytes mean, and 113.04KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.uncachable.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'cachable and not' class.




24. Object 'cachable and not'

contribution: 79.43% by count and 85.58% by volume
rates: 9.71xact/sec or 0.83Mbits/sec
totals: 0.01Mxact and 0.12GByte
response time: 0.00msec min, 2556.10msec mean, and 12113.00msec max
response size: 0.27KBytes min, 11.00KBytes mean, and 1304.11KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.all_cachable.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




25. Object 'fill'

contribution: 45.42% by count and 52.78% by volume
rates: 5.55xact/sec or 0.51Mbits/sec
totals: 0.01Mxact and 0.08GByte
response time: 0.00msec min, 2561.15msec mean, and 12113.00msec max
response size: 0.33KBytes min, 11.86KBytes mean, and 1304.11KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.fill.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




26. Object 'reload'

contribution: 11.54% by count and 8.80% by volume
rates: 1.41xact/sec or 0.09Mbits/sec
totals: 0.00Mxact and 0.01GByte
response time: 0.00msec min, 2508.70msec mean, and 13479.00msec max
response size: 0.00KBytes min, 7.79KBytes mean, and 1304.10KBytes max
response time distribution
object.reload.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.reload.size.fig.scope=sides=server__phases=inc2
response time trace
object.reload.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




27. Object 'abort'

contribution: 0.08% by count and 0.03% by volume
rates: 0.01xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 507.00msec min, 2350.58msec mean, and 3938.00msec max
response size: 0.00KBytes min, 3.77KBytes mean, and 32.52KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.abort.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




28. Object 'redirected request'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all replies' class.




29. Object 'reply to redirect'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all replies' class.




30. Object 'HEAD'

contribution: 0.03% by count and 0.00% by volume
rates: 0.00xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 1801.00msec min, 2296.00msec mean, and 3044.00msec max
response size: 0.29KBytes min, 0.34KBytes mean, and 0.35KBytes max
response time distribution
object.method_head.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.method_head.size.fig.scope=sides=server__phases=inc2
response time trace
object.method_head.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all non-gets' class.




31. Object 'POST'

contribution: 0.87% by count and 1.17% by volume
rates: 0.11xact/sec or 0.01Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 8.00msec min, 2599.07msec mean, and 5835.00msec max
response size: 0.41KBytes min, 13.76KBytes mean, and 414.03KBytes max
response time distribution
object.method_post.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.method_post.size.fig.scope=sides=server__phases=inc2
response time trace
object.method_post.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all non-gets' class.




32. Object 'PUT'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all non-gets' class.




33. Object 'all non-gets'

contribution: 0.89% by count and 1.17% by volume
rates: 0.11xact/sec or 0.01Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 8.00msec min, 2589.82msec mean, and 5835.00msec max
response size: 0.29KBytes min, 13.35KBytes mean, and 414.03KBytes max
response time distribution
object.method_all.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.method_all.size.fig.scope=sides=server__phases=inc2
response time trace
object.method_all.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.

This object class belongs to the 'all replies' class.




34. Object 'all replies'

contribution: 100.00% by count and 100.00% by volume
rates: 12.22xact/sec or 0.97Mbits/sec
totals: 0.01Mxact and 0.14GByte
response time: 0.00msec min, 2552.60msec mean, and 13479.00msec max
response size: 0.00KBytes min, 10.21KBytes mean, and 1304.11KBytes max
response time distribution
object.rep.rptm.fig.scope=sides=server__phases=inc2
object size distribution
object.rep.size.fig.scope=sides=server__phases=inc2
response time trace
object.rep.rptm.trace.scope=sides=server__phases=inc2

No description is available for this object class.
