2G-50-Writer-Retest: everything (scoped)

client side	baseline	all phases	framp	fill	fexit	inc1	top1	dec1	idle	inc2	top2	dec2
server side	baseline	all phases	framp	fill	fexit	inc1	top1	dec1	idle	inc2	top2	dec2
all sides	baseline	all phases	framp	fill	fexit	inc1	top1	dec1	idle	inc2	top2	dec2

highlighted cell(s) above show current scope
links point to other scopes

1. Load

Load	Count (xact/sec)	Volume (Mbits/sec)
offered	0.20	0.01
measured	0.20	0.01

Load trace

The load table shows offered and measured load from client side point of view. Offered load statistics are based on the request stream. Measured load statistics are based on reply messages. The 'count' column depicts the number of requests or responses.

The 'volume' column is a little bit more tricky to interpret. Offered volume is reply bandwidth that would have been required to support offered load. This volume is computed as request rate multiplied by measured mean response size. Measured volume is the actual or measured reply bandwidth.

2. Hit Ratios

Hit Ratios	DHR (%)	BHR (%)
offered	55.64	33.31
measured	37.99	22.02

The hit ratios table shows offered and measured hit ratios from client side point of view. Polygraph counts every repeated request to a cachable object as an offered hit. Measured (cache) hits are detected using Polygraph-specific headers. All hits are counted for 'basic' transactions only (simple HTTP GET requests with '200 OK' responses).

DHR, Document Hit Ratio, is the ratio of the total number of hits to the number of all basic transactions (hits and misses). BHR, Byte Hit Ratio, is the ratio of the total volume (a sum of response sizes) of hits to the total volume of all basic transactions.

A better way to measure hit ratio is to compare client- and server-side traffic. A hit ratio table based on such a comparison is available elsewhere.

3. Concurrent HTTP transaction level table

Transaction state	Number of times		Mean concurrency level
	entered	left
active	516.00	520.00	501.11
waiting	1854.00	250893.00	87453.63

concurrent HTTP transaction level trace

TBD.

4. Concurrent HTTP/TCP connection level table

Connection state	Number of times		Mean concurrency level
	entered	left
open	99.00	103.00	501.11
established	134.00	62.00	460.30

concurrent HTTP/TCP connection level trace

TBD.

5. Population level table

Number of agents		Mean population level
created	destroyed
0.00	124.00	96.96

population level trace

Populus is a set of all live robot or server agents. While alive, an agent may participate in HTTP transactions or remain idle.

6. Traffic stream table

Stream	Contribution		Rates		Totals
	Count (%)	Volume (%)	Count (xact/sec)	Volume (Mbits/sec)	Count (xact,M)	Volume (Gbyte)
"foreign"	0.00	0.00	0.00	0.00	0.00	0.00
"image"	52.15	32.93	0.09	0.00	0.00	0.00
"HTML"	22.32	13.40	0.04	0.00	0.00	0.00
"download"	0.00	0.00	0.00	0.00	0.00	0.00
"applet"	0.43	0.35	0.00	0.00	0.00	0.00
"other"	12.66	41.14	0.02	0.00	0.00	0.00
all content types	87.55	87.82	0.15	0.01	0.00	0.00
hits	33.26	19.34	0.06	0.00	0.00	0.00
misses	54.29	68.48	0.10	0.01	0.00	0.00
hits and misses	87.55	87.82	0.15	0.01	0.00	0.00
ims/200	4.72	4.55	0.01	0.00	0.00	0.00
ims/304	2.36	0.04	0.00	0.00	0.00	0.00
all ims	7.08	4.59	0.01	0.00	0.00	0.00
cachable	69.74	62.41	0.12	0.01	0.00	0.00
not cachable	17.81	25.41	0.03	0.00	0.00	0.00
cachable and not	87.55	87.82	0.15	0.01	0.00	0.00
fill	36.48	43.07	0.06	0.00	0.00	0.00
reload	5.36	7.59	0.01	0.00	0.00	0.00
abort	0.43	0.12	0.00	0.00	0.00	0.00
redirected request	0.00	0.00	0.00	0.00	0.00	0.00
reply to redirect	0.00	0.00	0.00	0.00	0.00	0.00
HEAD	0.00	0.00	0.00	0.00	0.00	0.00
POST	0.00	0.00	0.00	0.00	0.00	0.00
PUT	0.00	0.00	0.00	0.00	0.00	0.00
all non-gets	0.00	0.00	0.00	0.00	0.00	0.00
all replies	100.00	100.00	0.18	0.01	0.00	0.00

The 'Stream' table provides count and volume statistics for many classes of transactions. The 'Contribution' columns show count- and volume-based portions of all transactions. The 'Rates' columns show throughput and bandwidth measurements. The 'Totals' columns contain the total number of transactions and the total volume (a sum of individual response sizes) for each stream.

Note that some streams are a combination of other streams. For example, the 'all ims' stream contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' stream) or '304 Not Modified' (the 'ims/304' stream) responses.

Many combination streams, such as 'all content types' or 'hits and misses' stream, contribute less than 100% because properties like content type or hit status are distinguished for 'basic' transactions only. A basic transactions is a simple HTTP GET request resulted in a '200 OK' response. Various special transactions such as IMS or aborts do not belong to the 'basic' category.

The 'Object' table contains corresponding response time and size statistics for streams.

7. Object kind table

Object	Response time (msec)			Size (KBytes)
	Min	Mean	Max	Min	Mean	Max
"foreign"	n/a	n/a	n/a	n/a	n/a	n/a
"image"	n/a	n/a	n/a	0.39	4.83	30.81
"HTML"	n/a	n/a	n/a	0.40	4.59	34.10
"download"	n/a	n/a	n/a	n/a	n/a	n/a
"applet"	n/a	n/a	n/a	3.00	6.24	9.48
"other"	n/a	n/a	n/a	11.21	24.84	53.69
all content types	n/a	n/a	n/a	0.39	7.67	53.69
hits	3104.00	58537.12	257889.00	0.42	4.45	30.81
misses	928.00	58160.20	285324.00	0.39	9.64	53.69
hits and misses	928.00	58303.39	285324.00	0.39	7.67	53.69
ims/200	2391.00	64917.09	332111.00	0.44	7.37	62.44
ims/304	3888.00	60634.27	138429.00	0.13	0.14	0.16
all ims	2391.00	63489.48	332111.00	0.13	4.96	62.44
cachable	928.00	58135.86	285324.00	0.39	6.84	53.02
not cachable	1205.00	58959.39	237885.00	0.47	10.91	53.69
cachable and not	928.00	58303.39	285324.00	0.39	7.67	53.69
fill	928.00	57770.01	285324.00	0.39	9.03	53.02
reload	1110.00	55506.24	158066.00	0.75	10.82	34.22
abort	8198.00	38629.00	69060.00	0.87	2.18	3.49
redirected request	n/a	n/a	n/a	n/a	n/a	n/a
reply to redirect	n/a	n/a	n/a	n/a	n/a	n/a
HEAD	n/a	n/a	n/a	n/a	n/a	n/a
POST	n/a	n/a	n/a	n/a	n/a	n/a
PUT	n/a	n/a	n/a	n/a	n/a	n/a
all non-gets	n/a	n/a	n/a	n/a	n/a	n/a
all replies	928.00	58520.59	332111.00	0.13	7.65	62.44

The 'Object' table provides response time and response size statistics for many classes of transactions.

Note that some classes are a combination of other classes. For example, the 'all ims' class contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' class) or '304 Not Modified' (the 'ims/304' class) responses.

Some statistics may not be available because either no objects of the corresponding class were seen during the test or no facilities to collect the stats exist for the class. The former can be verified using a 'Stream' table.

8. Errors

The total of 61 errors detected. Out of those errors, 52xact or 10.00% of all transactions were classified as transaction errors.

Error	Count	Contribution (%)
(s110) Connection timed out	44	72.13
(c54) internal timers may be getting behind	9	14.75
(c17) connection closed before sending headers	6	9.84
(s104) Connection reset by peer	2	3.28

The 'Errors' table shows detected errors. For each error type, the number of errors and their contribution towards total error count are shown.

9. Object '"foreign"'

No instances of this object class were observed or recorded in the given scope.

This object class represents one of the content types specified in the PGL workload file and labeled there as "foreign".

10. Object '"image"'

contribution:	52.15% by count and 32.93% by volume
rates:	0.09xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	n/a min, n/a mean, and n/a max
response size:	0.39KBytes min, 4.83KBytes mean, and 30.81KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.

This object class represents one of the content types specified in the PGL workload file and labeled there as "image".

11. Object '"HTML"'

contribution:	22.32% by count and 13.40% by volume
rates:	0.04xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	n/a min, n/a mean, and n/a max
response size:	0.40KBytes min, 4.59KBytes mean, and 34.10KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.

This object class represents one of the content types specified in the PGL workload file and labeled there as "HTML".

12. Object '"download"'

No instances of this object class were observed or recorded in the given scope.

This object class represents one of the content types specified in the PGL workload file and labeled there as "download".

13. Object '"applet"'

contribution:	0.43% by count and 0.35% by volume
rates:	0.00xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	n/a min, n/a mean, and n/a max
response size:	3.00KBytes min, 6.24KBytes mean, and 9.48KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.

This object class represents one of the content types specified in the PGL workload file and labeled there as "applet".

14. Object '"other"'

contribution:	12.66% by count and 41.14% by volume
rates:	0.02xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	n/a min, n/a mean, and n/a max
response size:	11.21KBytes min, 24.84KBytes mean, and 53.69KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.

This object class represents one of the content types specified in the PGL workload file and labeled there as "other".

15. Object 'all content types'

contribution:	87.55% by count and 87.82% by volume
rates:	0.15xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	n/a min, n/a mean, and n/a max
response size:	0.39KBytes min, 7.67KBytes mean, and 53.69KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.

No description is available for this object class.

This object class belongs to the 'all replies' class.

16. Object 'hits'

contribution:	33.26% by count and 19.34% by volume
rates:	0.06xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	3104.00msec min, 58537.12msec mean, and 257889.00msec max
response size:	0.42KBytes min, 4.45KBytes mean, and 30.81KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.

This object class belongs to the 'hits and misses' class.

17. Object 'misses'

contribution:	54.29% by count and 68.48% by volume
rates:	0.10xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 58160.20msec mean, and 285324.00msec max
response size:	0.39KBytes min, 9.64KBytes mean, and 53.69KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.

This object class belongs to the 'hits and misses' class.

18. Object 'hits and misses'

contribution:	87.55% by count and 87.82% by volume
rates:	0.15xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 58303.39msec mean, and 285324.00msec max
response size:	0.39KBytes min, 7.67KBytes mean, and 53.69KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

19. Object 'ims/200'

contribution:	4.72% by count and 4.55% by volume
rates:	0.01xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	2391.00msec min, 64917.09msec mean, and 332111.00msec max
response size:	0.44KBytes min, 7.37KBytes mean, and 62.44KBytes max

response time distribution

object size distribution

No response time and size traces are collected for this object class.

No description is available for this object class.

This object class belongs to the 'all ims' class.

20. Object 'ims/304'

contribution:	2.36% by count and 0.04% by volume
rates:	0.00xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	3888.00msec min, 60634.27msec mean, and 138429.00msec max
response size:	0.13KBytes min, 0.14KBytes mean, and 0.16KBytes max

response time distribution

object size distribution

No response time and size traces are collected for this object class.

No description is available for this object class.

This object class belongs to the 'all ims' class.

21. Object 'all ims'

contribution:	7.08% by count and 4.59% by volume
rates:	0.01xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	2391.00msec min, 63489.48msec mean, and 332111.00msec max
response size:	0.13KBytes min, 4.96KBytes mean, and 62.44KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

22. Object 'cachable'

contribution:	69.74% by count and 62.41% by volume
rates:	0.12xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 58135.86msec mean, and 285324.00msec max
response size:	0.39KBytes min, 6.84KBytes mean, and 53.02KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace

No description is available for this object class.

This object class belongs to the 'cachable and not' class.

23. Object 'not cachable'

contribution:	17.81% by count and 25.41% by volume
rates:	0.03xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	1205.00msec min, 58959.39msec mean, and 237885.00msec max
response size:	0.47KBytes min, 10.91KBytes mean, and 53.69KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace

No description is available for this object class.

This object class belongs to the 'cachable and not' class.

24. Object 'cachable and not'

contribution:	87.55% by count and 87.82% by volume
rates:	0.15xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 58303.39msec mean, and 285324.00msec max
response size:	0.39KBytes min, 7.67KBytes mean, and 53.69KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

25. Object 'fill'

contribution:	36.48% by count and 43.07% by volume
rates:	0.06xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 57770.01msec mean, and 285324.00msec max
response size:	0.39KBytes min, 9.03KBytes mean, and 53.02KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

26. Object 'reload'

contribution:	5.36% by count and 7.59% by volume
rates:	0.01xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	1110.00msec min, 55506.24msec mean, and 158066.00msec max
response size:	0.75KBytes min, 10.82KBytes mean, and 34.22KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

27. Object 'abort'

contribution:	0.43% by count and 0.12% by volume
rates:	0.00xact/sec or 0.00Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	8198.00msec min, 38629.00msec mean, and 69060.00msec max
response size:	0.87KBytes min, 2.18KBytes mean, and 3.49KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace

No description is available for this object class.

This object class belongs to the 'all replies' class.

28. Object 'redirected request'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all replies' class.

29. Object 'reply to redirect'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all replies' class.

30. Object 'HEAD'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all non-gets' class.

31. Object 'POST'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all non-gets' class.

32. Object 'PUT'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all non-gets' class.

33. Object 'all non-gets'

No instances of this object class were observed or recorded in the given scope.

No description is available for this object class.

This object class belongs to the 'all replies' class.

34. Object 'all replies'

contribution:	100.00% by count and 100.00% by volume
rates:	0.18xact/sec or 0.01Mbits/sec
totals:	0.00Mxact and 0.00GByte
response time:	928.00msec min, 58520.59msec mean, and 332111.00msec max
response size:	0.13KBytes min, 7.65KBytes mean, and 62.44KBytes max

response time distribution

object size distribution

response time trace

No description is available for this object class.
