2G-50-Writer-Retest: everything (scoped)
client side baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
server side baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
all sides baseline all phases framp fill fexit inc1 top1 dec1 idle inc2 top2 dec2
highlighted cell(s) above show current scope
links point to other scopes

1. Load

Load Count
(xact/sec)		 Volume
(Mbits/sec)
offered 12.90 1.17
measured 12.90 1.17
Load trace
load.trace.scope=sides=server__phases=framp

The load table shows offered and measured load from server side point of view. Offered load statistics are based on the request stream. Measured load statistics are based on reply messages. The 'count' column depicts the number of requests or responses.

The 'volume' column is a little bit more tricky to interpret. Offered volume is reply bandwidth that would have been required to support offered load. This volume is computed as request rate multiplied by measured mean response size. Measured volume is the actual or measured reply bandwidth.




2. Hit Ratios

Hit Ratios DHR
(%)		 BHR
(%)
offered 0.00 0.00
measured 0.00 0.00

The server-side hit ratios should always be zero. If a request reaches a server, it is, by definition, a miss.

A better way to measure hit ratio is to compare client- and server-side traffic. A hit ratio table based on such a comparison is available elsewhere.




3. Concurrent HTTP transaction level table

Transaction state Number of times Mean concurrency level
entered left
active 15480.00 15479.00 0.54
waiting 0.00 0.00 0.00
concurrent HTTP transaction level trace
xact.level.trace.scope=sides=server__phases=framp

TBD.




4. Concurrent HTTP/TCP connection level table

Connection state Number of times Mean concurrency level
entered left
open 15546.00 15478.00 33.83
established 15546.00 15478.00 33.82
concurrent HTTP/TCP connection level trace
conn.level.trace.scope=sides=server__phases=framp

TBD.




5. Population level table

Number of agents Mean population level
created destroyed
513.00 0.00 513.00
population level trace
populus.level.trace.scope=sides=server__phases=framp

Populus is a set of all live robot or server agents. While alive, an agent may participate in HTTP transactions or remain idle.




6. Traffic stream table

Stream Contribution Rates Totals
Count
(%)		 Volume
(%)		 Count
(xact/sec)		 Volume
(Mbits/sec)		 Count
(xact,M)		 Volume
(Gbyte)
"foreign" 0.00 0.00 0.00 0.00 0.00 0.00
"image" 61.52 24.84 7.93 0.29 0.01 0.04
"HTML" 16.32 13.99 2.10 0.16 0.00 0.02
"download" 0.81 16.25 0.10 0.19 0.00 0.03
"applet" 0.22 0.09 0.03 0.00 0.00 0.00
"other" 19.96 44.15 2.57 0.52 0.00 0.08
all content types 98.83 99.32 12.73 1.16 0.02 0.17
hits 0.00 0.00 0.00 0.00 0.00 0.00
misses 98.83 99.32 12.73 1.16 0.02 0.17
hits and misses 98.83 99.32 12.73 1.16 0.02 0.17
ims/200 0.36 0.27 0.05 0.00 0.00 0.00
ims/304 0.25 0.00 0.03 0.00 0.00 0.00
all ims 0.61 0.28 0.08 0.00 0.00 0.00
cachable 79.70 81.04 10.27 0.95 0.01 0.14
not cachable 19.13 18.28 2.46 0.21 0.00 0.03
cachable and not 98.83 99.32 12.73 1.16 0.02 0.17
fill 79.70 81.04 10.27 0.95 0.01 0.14
reload 0.52 0.36 0.07 0.00 0.00 0.00
abort 0.12 0.02 0.01 0.00 0.00 0.00
redirected request 0.00 0.00 0.00 0.00 0.00 0.00
reply to redirect 0.00 0.00 0.00 0.00 0.00 0.00
HEAD 0.01 0.00 0.00 0.00 0.00 0.00
POST 0.04 0.04 0.00 0.00 0.00 0.00
PUT 0.00 0.00 0.00 0.00 0.00 0.00
all non-gets 0.05 0.04 0.01 0.00 0.00 0.00
all replies 100.00 100.00 12.88 1.17 0.02 0.17

The 'Stream' table provides count and volume statistics for many classes of transactions. The 'Contribution' columns show count- and volume-based portions of all transactions. The 'Rates' columns show throughput and bandwidth measurements. The 'Totals' columns contain the total number of transactions and the total volume (a sum of individual response sizes) for each stream.

Note that some streams are a combination of other streams. For example, the 'all ims' stream contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' stream) or '304 Not Modified' (the 'ims/304' stream) responses.

Many combination streams, such as 'all content types' or 'hits and misses' stream, contribute less than 100% because properties like content type or hit status are distinguished for 'basic' transactions only. A basic transactions is a simple HTTP GET request resulted in a '200 OK' response. Various special transactions such as IMS or aborts do not belong to the 'basic' category.

The 'Object' table contains corresponding response time and size statistics for streams.




7. Object kind table

Object Response time (msec) Size (KBytes)
Min Mean Max Min Mean Max
"foreign" n/a n/a n/a n/a n/a n/a
"image" n/a n/a n/a 0.27 4.69 41.85
"HTML" n/a n/a n/a 0.37 9.96 63.90
"download" n/a n/a n/a 18.30 231.51 509.55
"applet" n/a n/a n/a 1.58 4.95 7.29
"other" n/a n/a n/a 7.67 25.69 72.60
all content types n/a n/a n/a 0.27 11.67 509.55
hits n/a n/a n/a n/a n/a n/a
misses 0.00 2564.76 14111.00 0.27 11.67 509.55
hits and misses 0.00 2564.76 14111.00 0.27 11.67 509.55
ims/200 2.00 2265.07 4108.00 0.30 8.97 67.97
ims/304 1014.00 2677.36 4934.00 0.06 0.11 0.13
all ims 2.00 2436.13 4934.00 0.06 5.29 67.97
cachable 0.00 2570.96 14111.00 0.33 11.81 509.55
not cachable 0.00 2538.93 6059.00 0.27 11.10 113.04
cachable and not 0.00 2564.76 14111.00 0.27 11.67 509.55
fill 0.00 2570.96 14111.00 0.33 11.81 509.55
reload 270.00 2506.45 4505.00 0.40 8.11 47.24
abort 918.00 2853.83 5116.00 0.00 2.12 25.45
redirected request n/a n/a n/a n/a n/a n/a
reply to redirect n/a n/a n/a n/a n/a n/a
HEAD 2477.00 2477.00 2477.00 0.35 0.35 0.35
POST 1211.00 2528.50 5132.00 0.44 10.91 29.28
PUT n/a n/a n/a n/a n/a n/a
all non-gets 1211.00 2521.14 5132.00 0.35 9.40 29.28
all replies 0.00 2563.65 14111.00 0.06 11.61 509.55

The 'Object' table provides response time and response size statistics for many classes of transactions.

Note that some classes are a combination of other classes. For example, the 'all ims' class contains transactions with If-Modified-Since requests that resulted in either '200 OK' (the 'ims/304' class) or '304 Not Modified' (the 'ims/304' class) responses.

Some statistics may not be available because either no objects of the corresponding class were seen during the test or no facilities to collect the stats exist for the class. The former can be verified using a 'Stream' table.




8. Errors

No errors detected in the given scope.


9. Object '"foreign"'

No instances of this object class were observed or recorded in the given scope.


This object class represents one of the content types specified in the PGL workload file and labeled there as "foreign".


10. Object '"image"'

contribution: 61.52% by count and 24.84% by volume
rates: 7.93xact/sec or 0.29Mbits/sec
totals: 0.01Mxact and 0.04GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.27KBytes min, 4.69KBytes mean, and 41.85KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "image".


11. Object '"HTML"'

contribution: 16.32% by count and 13.99% by volume
rates: 2.10xact/sec or 0.16Mbits/sec
totals: 0.00Mxact and 0.02GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.37KBytes min, 9.96KBytes mean, and 63.90KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "HTML".


12. Object '"download"'

contribution: 0.81% by count and 16.25% by volume
rates: 0.10xact/sec or 0.19Mbits/sec
totals: 0.00Mxact and 0.03GByte
response time: n/a min, n/a mean, and n/a max
response size: 18.30KBytes min, 231.51KBytes mean, and 509.55KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "download".


13. Object '"applet"'

contribution: 0.22% by count and 0.09% by volume
rates: 0.03xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: n/a min, n/a mean, and n/a max
response size: 1.58KBytes min, 4.95KBytes mean, and 7.29KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "applet".


14. Object '"other"'

contribution: 19.96% by count and 44.15% by volume
rates: 2.57xact/sec or 0.52Mbits/sec
totals: 0.00Mxact and 0.08GByte
response time: n/a min, n/a mean, and n/a max
response size: 7.67KBytes min, 25.69KBytes mean, and 72.60KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


This object class represents one of the content types specified in the PGL workload file and labeled there as "other".


15. Object 'all content types'

contribution: 98.83% by count and 99.32% by volume
rates: 12.73xact/sec or 1.16Mbits/sec
totals: 0.02Mxact and 0.17GByte
response time: n/a min, n/a mean, and n/a max
response size: 0.27KBytes min, 11.67KBytes mean, and 509.55KBytes max

No response time and size histograms were collected or stored for this object class.

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all replies' class.




16. Object 'hits'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'hits and misses' class.




17. Object 'misses'

contribution: 98.83% by count and 99.32% by volume
rates: 12.73xact/sec or 1.16Mbits/sec
totals: 0.02Mxact and 0.17GByte
response time: 0.00msec min, 2564.76msec mean, and 14111.00msec max
response size: 0.27KBytes min, 11.67KBytes mean, and 509.55KBytes max
response time distribution
object.misses.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.misses.size.fig.scope=sides=server__phases=framp
response time trace
object.misses.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'hits and misses' class.




18. Object 'hits and misses'

contribution: 98.83% by count and 99.32% by volume
rates: 12.73xact/sec or 1.16Mbits/sec
totals: 0.02Mxact and 0.17GByte
response time: 0.00msec min, 2564.76msec mean, and 14111.00msec max
response size: 0.27KBytes min, 11.67KBytes mean, and 509.55KBytes max
response time distribution
object.hits_and_misses.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.hits_and_misses.size.fig.scope=sides=server__phases=framp
response time trace
object.hits_and_misses.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




19. Object 'ims/200'

contribution: 0.36% by count and 0.27% by volume
rates: 0.05xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 2.00msec min, 2265.07msec mean, and 4108.00msec max
response size: 0.30KBytes min, 8.97KBytes mean, and 67.97KBytes max
response time distribution
object.ims_sc200.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.ims_sc200.size.fig.scope=sides=server__phases=framp

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all ims' class.




20. Object 'ims/304'

contribution: 0.25% by count and 0.00% by volume
rates: 0.03xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 1014.00msec min, 2677.36msec mean, and 4934.00msec max
response size: 0.06KBytes min, 0.11KBytes mean, and 0.13KBytes max
response time distribution
object.ims_sc304.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.ims_sc304.size.fig.scope=sides=server__phases=framp

No response time and size traces are collected for this object class.


No description is available for this object class.

This object class belongs to the 'all ims' class.




21. Object 'all ims'

contribution: 0.61% by count and 0.28% by volume
rates: 0.08xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 2.00msec min, 2436.13msec mean, and 4934.00msec max
response size: 0.06KBytes min, 5.29KBytes mean, and 67.97KBytes max
response time distribution
object.ims_scAll.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.ims_scAll.size.fig.scope=sides=server__phases=framp
response time trace
object.ims_scAll.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




22. Object 'cachable'

contribution: 79.70% by count and 81.04% by volume
rates: 10.27xact/sec or 0.95Mbits/sec
totals: 0.01Mxact and 0.14GByte
response time: 0.00msec min, 2570.96msec mean, and 14111.00msec max
response size: 0.33KBytes min, 11.81KBytes mean, and 509.55KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.cachable.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'cachable and not' class.




23. Object 'not cachable'

contribution: 19.13% by count and 18.28% by volume
rates: 2.46xact/sec or 0.21Mbits/sec
totals: 0.00Mxact and 0.03GByte
response time: 0.00msec min, 2538.93msec mean, and 6059.00msec max
response size: 0.27KBytes min, 11.10KBytes mean, and 113.04KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.uncachable.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'cachable and not' class.




24. Object 'cachable and not'

contribution: 98.83% by count and 99.32% by volume
rates: 12.73xact/sec or 1.16Mbits/sec
totals: 0.02Mxact and 0.17GByte
response time: 0.00msec min, 2564.76msec mean, and 14111.00msec max
response size: 0.27KBytes min, 11.67KBytes mean, and 509.55KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.all_cachable.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




25. Object 'fill'

contribution: 79.70% by count and 81.04% by volume
rates: 10.27xact/sec or 0.95Mbits/sec
totals: 0.01Mxact and 0.14GByte
response time: 0.00msec min, 2570.96msec mean, and 14111.00msec max
response size: 0.33KBytes min, 11.81KBytes mean, and 509.55KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.fill.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




26. Object 'reload'

contribution: 0.52% by count and 0.36% by volume
rates: 0.07xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 270.00msec min, 2506.45msec mean, and 4505.00msec max
response size: 0.40KBytes min, 8.11KBytes mean, and 47.24KBytes max
response time distribution
object.reload.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.reload.size.fig.scope=sides=server__phases=framp
response time trace
object.reload.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




27. Object 'abort'

contribution: 0.12% by count and 0.02% by volume
rates: 0.01xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 918.00msec min, 2853.83msec mean, and 5116.00msec max
response size: 0.00KBytes min, 2.12KBytes mean, and 25.45KBytes max

No response time and size histograms were collected or stored for this object class.

response time trace
object.abort.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




28. Object 'redirected request'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all replies' class.




29. Object 'reply to redirect'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all replies' class.




30. Object 'HEAD'

contribution: 0.01% by count and 0.00% by volume
rates: 0.00xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 2477.00msec min, 2477.00msec mean, and 2477.00msec max
response size: 0.35KBytes min, 0.35KBytes mean, and 0.35KBytes max
response time distribution
object.method_head.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.method_head.size.fig.scope=sides=server__phases=framp
response time trace
object.method_head.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all non-gets' class.




31. Object 'POST'

contribution: 0.04% by count and 0.04% by volume
rates: 0.00xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 1211.00msec min, 2528.50msec mean, and 5132.00msec max
response size: 0.44KBytes min, 10.91KBytes mean, and 29.28KBytes max
response time distribution
object.method_post.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.method_post.size.fig.scope=sides=server__phases=framp
response time trace
object.method_post.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all non-gets' class.




32. Object 'PUT'

No instances of this object class were observed or recorded in the given scope.


No description is available for this object class.

This object class belongs to the 'all non-gets' class.




33. Object 'all non-gets'

contribution: 0.05% by count and 0.04% by volume
rates: 0.01xact/sec or 0.00Mbits/sec
totals: 0.00Mxact and 0.00GByte
response time: 1211.00msec min, 2521.14msec mean, and 5132.00msec max
response size: 0.35KBytes min, 9.40KBytes mean, and 29.28KBytes max
response time distribution
object.method_all.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.method_all.size.fig.scope=sides=server__phases=framp
response time trace
object.method_all.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.

This object class belongs to the 'all replies' class.




34. Object 'all replies'

contribution: 100.00% by count and 100.00% by volume
rates: 12.88xact/sec or 1.17Mbits/sec
totals: 0.02Mxact and 0.17GByte
response time: 0.00msec min, 2563.65msec mean, and 14111.00msec max
response size: 0.06KBytes min, 11.61KBytes mean, and 509.55KBytes max
response time distribution
object.rep.rptm.fig.scope=sides=server__phases=framp
object size distribution
object.rep.size.fig.scope=sides=server__phases=framp
response time trace
object.rep.rptm.trace.scope=sides=server__phases=framp

No description is available for this object class.
